Comet Smart Flash Cure Unit

NEW
View 360 View 360
  • Quartz lamps heat up and shut down quickly, saving electricity compared to infrared flashes which are always on
  • Two or three curing zones, depending on the size of the flash
  • Built-in temperature sensor allows you to program your desired curing temperature
  • Compatible with Anatol automatic presses, or add the optional Smart Box (see below) for use with a manual press or other manufacturer’s automatic
  • Models available with 16” x 18”, 20” x 24” and 20” x 28” curing areas

To use the Comet Smart flash cure unit with an Anatol manual press or another manufacturer’s automatic/manual press, add the optional Smart Box.

Additional Smart Box More info
Get a Quote

Program your desired curing time and temperature for more effective flash curing.

Anatol’s Comet Smart flash cure unit gives you the power and efficiency of quartz flashing, plus the ability to set a desired curing temperature with its built-in temperature sensor. Program your curing temperature from the touchscreen of your Anatol automatic screen printing press, or from the optional Smart Box onboard touchscreen control panel (for use with manual presses or other manufacturers’ automatics). The Comet Smart will heat up to and maintain your desired temperature for your set time, reducing the chances of scorching or burning shirts. Like all flashes in the Comet series, the quartz lamps will automatically and deactivate, so they’re only on when you need them to be – saving electricity compared to infrared flash cures which are always on. The Comet Smart is available in three different curing areas – 16″ x 18″, 20″ x 24”, and 20″ x 28″.

Take more control over your flash cure settings with the Comet Smart.
  • Set your desired flash time and temperature from the touchscreen of your Anatol automatic screen printing press, or from the optional Smart Box onboard touchscreen control panel (for use with manual presses or other manufacturers’ automatics).
  • Temperature sensor allows you to set your flash temperature for more effective curing, and reduces the chances of scorching or burning shirts.
  • Pallet sensor detects when a shirt is under the flash for automatic activation/deactivation – so the lamps are only “on” whenever necessary; reducing energy when compared to infrared flashes which are always on.
  • Quartz lamps heat up and cool down quickly.
  • Multiple curing zones – two or three zones depending on the size of the flash (see Specifications).
  • Available on a height-adjustable floor stand for use with both Anatol automatic and manual screen printing presses.

Comet Smart Specifications

COMET LIGHT
SIZE
NUMBER
OF LAMPS
NUMBER OF CURING ZONESHEAT FLUX DENSITELECTRICAL REQUIREMENTS*
16”x 18”
46.0х96.9cm
(52.3×96.9cm)**
9 Lamps2 zones
(Zone I -6 lamps, Zone II – 3 lamps)
4.47 W/cm2
(28.87 W/in2)
1 Ph, 208-240V, 50/60 Hz, 9kW, 40A
3 Ph, 208V, 23A
20”x 24”
58.0×110.4cm
(64.3×110.4cm)**
10 Lamps2 zones
(Zone I -6 lamps, Zone II – 4 lamps)
3.8 W/cm2
(24.53 W/in2)
1 Ph, 208-240V, 50/60 Hz, 12.5kW, 55A
3 Ph, 208V, 32A
20”x 28”
58.0×120.0cm
(64.3×120.0cm)**
15 Lamps3 zones
(Zone I -5 lamps, Zone II – 5 lamps,
Zone III – 5 lamps)
4.9 W/cm2
(31.61 W/in2)
1 Ph, 208-240V, 50/60 Hz, 18.75kW, 82A
3 Ph, 208V, 47A
* The maximum power consumption is calculated for all lamps operating at maximum power
** The dimensions in parentheses mean are the dimensions with the electrical box included

Download Brochure

Download Brochure

Certification & Warranty

Certification & Warranty

Equipment Certification

European Committee for Standardization® (CE) and Underwriters Laboratories® (UL) compliant: built to specifications established by both CE and UL

All equipment shipped to Canada is Approved under the Special Inspection Program per SPE-1000

Premium service that will exceed your expectations

Customer Service and Support are a way of life at Anatol Equipment. We strive to improve our service to keep your equipment running like the day you had it installed. This is our commitment to every customer. Two-year limited warranty.
