View 360The speed and efficiency of quartz flash curing in our most affordable package.
Anatol’s Comet Light flash cure unit was designed to boost your shop’s efficiency compared to infrared flashes, while being accessible to shops on a budget. Just set your curing time and the optical sensor on the flash unit will automatically detect when a shirt is underneath, activating and deactivating the lamps accordingly. The Comet Light is available in three different curing areas – 16″ x 18″, 20″ x 24”, and 20″ x 28″ – and is compatible with Anatol automatic presses, as well as manual presses with the addition of the optional Timer Box (see above).
A smart alternative to infrared flash cure units at an accessible price point.
- Set your desired flash time from the touchscreen of your Anatol automatic press, or from the easy-to-use digital controller (on optional Timer Box).
- Pallet sensor detects when a shirt is under the flash for automatic activation/deactivation – so the lamps are only “on” whenever necessary; reducing energy when compared to infrared flashes which are always on.
- Quartz lamps heat up and cool down quickly.
- Multiple curing zones – two or three zones depending on the size of the flash (see Specifications).
- Available on a height-adjustable floor stand for use with both Anatol automatic and manual screen printing presses.
- A smart alternative to infrared curing at an affordable price.
- Set the desired flash time on the touchscreen of the Anatol automatic press or with the easy-to-use digital controller (on the optional timer unit).
- A pallet sensor detects when the shirt is under the flash to automatically activate/deactivate – so the lamps are only switched on when needed; this reduces energy consumption compared to infrared flashes that are always on.
- Quartz lamps heat up and cool down quickly.
- Multiple curing zones – two or three zones depending on the flash size (see specifications).
- Available on a height-adjustable stand for use with both Anatol automatic and manual screen printing machines.
The Smart Flash Polymerization Unit is an efficient system for polymerizing your products. The Smart Flash Curing Unit is indispensable for screen printing, silk screening and t-shirt printing. Mobility and energy savings in production have always been considered good indicators. That is why the Anatol quartz curing unit is in high demand in the screen printing market.
Comet Light Specifications
| COMET LIGHT SIZE | NUMBER OF LAMPS | NUMBER OF CURING ZONES | HEAT FLUX DENSITY | ELECTRICAL REQUIREMENTS* |
|---|---|---|---|---|
| 16”x 18” 46.0х96.9cm (52.3×96.9cm)** | 9 Lamps | 2 zones (Zone I -6 lamps, Zone II – 3 lamps) | 4.47 W/cm2 (28.87 W/in2) | 1 Ph, 208-240V, 50/60 Hz, 9kW, 43.3A 3 Ph, 208V, 28.9A |
| 20”x 24” 58.0×110.4cm (64.3×110.4cm)** | 10 Lamps | 2 zones (Zone I -6 lamps, Zone II – 4 lamps) | 3.8 W/cm2 (24.53 W/in2) | 1 Ph, 208-240V, 50/60 Hz, 12kW, 57.7A 3 Ph, 208V, 40.3A |
| 20”x 28” 58.0×120.0cm (64.3×120.0cm)** | 15 Lamps | 3 zones (Zone I -5 lamps, Zone II – 5 lamps, Zone III – 5 lamps) | 4.9 W/cm2 (31.61 W/in2) | 1 Ph, 208-240V, 50/60 Hz, 18.75kW, 90.1A 3 Ph, 208V, 57.6A |
| * The maximum power consumption is calculated for all lamps operating at maximum power ** The dimensions in parentheses mean are the dimensions with the electrical box included | ||||
