Pilot Flash Cure Unit

Precise control over efficient flash curing for even your biggest prints.

Available in four sizes with a cure area of 16″, 20”, 30”, or 40”.

Get a Quote

Description

Anatol’s Pilot Flash quartz flash cure unit takes our ultra-fast medium-wave quartz lamps, and mobilizes them to give you total coverage of all substrates with our largest automatic machines; without the cost of an over-sized flash dryer. This flash cure unit is designed to clamp securely onto the print carriage to utilize the print/flood stroke, in order to move the flash within the print head. Like other Anatol quartz flash units, the Pilot Flash fully integrates with any Anatol automatic screen printing equipment touchscreen control panel. The Pilot Flash cure unit is available in four different widths: 16″, 20″, 30″, and 40″.

Standard features

Controls
  • Fully controllable from any Anatol Automatic Press control panel
  • Lamp Intensity control knob to fine tune the heat
Heating System
  • Quartz tube bulbs heat and cool quickly
  • Bulbs arranged horizontally, giving you more bulbs than similar flash units, with more control
  • Compact, mobile design to save on electricity compared to a traditional stationary flash cure
Construction
  • Can be mounted on the head of any Anatol automatic press
  • Heavy-duty steel construction

Pilot Flash Specifications

Model #WidthNumber of LampsElectrical Requirements
PILOT-1616″
41cm
41 Ph, 208-240V, 50/60 Hz, 4kW, 19A
3 Ph, 208-240V, 50/60 Hz, 4kW, 11A
PILOT-2020″
51cm
51 Ph, 208-240V, 50/60 Hz, 6kW, 31A
3 Ph, 208-240V, 50/60 Hz, 6kW, 18A
PILOT-3030″
71cm
121 Ph, 208-240V, 50/60 Hz, 12kW, 58A
3 Ph, 208-240V, 50/60 Hz, 12kW, 33A
PILOT-4040″
102cm
121 Ph, 208-240V, 50/60 Hz, 15kW, 72A
3 Ph, 208-240V, 50/60 Hz, 15kW, 42A

Download Brochure

Download Brochure

Certification & Warranty

Certification & Warranty

Two-Year Limited Warranty

Premium service that will exceed your expectations

Customer Service and Support are a way of life at Anatol Equipment. We strive to improve our service to keep your equipment running like the day you had it installed. This is our commitment to every customer. Two-year limited warranty.
