Description
Just because your shop is tight on space doesn’t mean you should have to sacrifice quality and settle for a conveyor dryer that’s less than industrial-grade. With that in mind, we’ve taken our full-size Solutions electric conveyor dryer and reduced the overall footprint down to 5’ long/3’ wide to create the SOLUTIONS MINI.
The Solutions Mini uses the same ceramic heating elements as our full size Solutions electric conveyor dryers, ensuring uniform heat distribution throughout the chamber for effective curing. High-efficiency thermal insulation keeps the outside of the dryer cool to the touch and keeps heat from migrating out of the chamber. The Solutions Mini includes precise and easy-to-use digital temperature controls as well as adjustable belt speed, to accommodate a wide variety of ink and substrate curing requirements. The belt tracking system ensures the belt is precisely aligned at all times. Models are available with single-phase wiring to accommodate facilities with single-phase electricity.
Standard Features
Design and Construction
- Space-saving design starting at a 24” wide belt, 2.5’ long heat chamber and 5’ overall length fits shops of all sizes
- Reliable thermal insulation prevents heat leakage from the dryer chamber to the work environment and boosts efficiency
- Adjustable infeed and outfeed openings to accommodate substrates of different sizes, minimizing heat escape
- Heavy-duty steel construction for ultimate durability
- The ideal conveyor dryer for a startup shop and perfect partner for a manual press or for smaller volume automatic screen printing
Control Center
- Precise and easy to use digital temperature controls
- Adjustable belt speed to accommodate different inks and garments
Heating Elements
- Ceramic heating elements ensure reliable and uniform distribution of heat in the chamber
- 2″ x 8″ elements arranged in a grid of 6-15 total elements, depending on dryer configuration (see Specifications)
Conveyor System
- Industrial-grade conveyor rollers
- Durable Teflon-coated fiberglass belt with speed control
- Belt tracking ensures the belt is precisely aligned at all times and prevents sliding to the right or left
- Reversible belt direction for maximum versatility
Options
- Custom dryer sizes (length/width)
- Infeed/outfeed extension(s) per customer requirements
- Outfeed cooling fan to boost ink cooling when substrate exits the heat chamber
Why Choose the Solutions Mini Compact Conveyor Dryer from Anatol?
The Solutions Mini Compact is the ideal solution for print shops seeking a compact, efficient, and reliable conveyor dryer.
Anatol dryer stands out from similar competitors with key advantages:
- Consistent, Even Heating
Equipped with ceramic heating elements, the Solutions Mini delivers uniform heat across the entire chamber, ensuring high-quality curing for every print — every time. - Compact Size, Maximum Performance
With an overall length of just 5 to 6.5 feet, this dryer is perfect for shops with limited space, small studios, or mobile setups — without compromising on performance. - Precise Digital Controls
The intuitive digital interface allows for accurate control of both temperature and conveyor belt speed, adapting seamlessly to various inks and garments. - Energy Efficiency & Operator Safety
Thanks to advanced thermal insulation, the dryer retains internal heat efficiently while keeping external surfaces cool to the touch — ensuring safety and reducing energy consumption.
The Solutions Mini Compact Conveyor Dryer combines precision, efficiency, and space-saving design in one reliable unit. If you’re looking for a dryer that delivers professional-level results without taking up valuable floor space, this is the solution your shop needs.
Solutions Mini Specifications
Model # | Belt Width | Oven Length | Standard Infeed/Outfeed Length | Wattage | Pieces per HR. | Ceramic Elements | Electrical Requirements |
---|---|---|---|---|---|---|---|
SEDM-2425 | 24″ 61cm | 2′6″ 76cm | 1’3″/1’3″ 38cm/38cm | 3900 W | 100-150 | 6 | 1 Ph, 208-230 V, 3.9 kW, 19A, 50/60Hz |
SEDM-2404 | 24″ 61cm | 4′0″ 122cm | 1’3″/1’3″ 38cm/38cm | 5850 W | 150-200 | 9 | 1 Ph, 208-230 V, 5.85 kW, 28A, 50/60Hz 3 Ph, 208-230 V, 5.85 kW, 16A, 50/60Hz |
SEDM-3625 | 36″ 92cm | 2′6″ 76cm | 1’3″/1’3″ 38cm/38cm | 5850 W | 150-200 | 9 | 1 Ph, 208-230 V, 5.85 kW, 29A, 50/60Hz 3 Ph, 208-230 V, 5.85 kW, 16A, 50/60Hz |
SEDM-4825 | 48″ 122cm | 2′6″ 76cm | 1’3″/1’3″ 38cm/38cm | 9750 W | 200-250 | 15 | 1 Ph, 208-230 V, 9.75 kW, 47A, 50/60Hz 3 Ph, 208-230 V, 9.75 kW, 27A, 50/60Hz |
