Electric Textile Dryer

Solutions Conveyor Dryer
Energy-efficient electric conveyor dryer



Energy-efficient electric conveyor dryer
Available in four basic models in configurations of 24” belt width/4’ heat – 60” belt width/10’ heat

When gas is not an option, Anatol electric screen printing conveyor dryers are the perfect Solution. The Solutions Series dryers are ideal for t-shirt and textile printers looking for an efficient and affordable curing unit. They feature more ceramic heating panels than similar dryers for even heat throughout the chamber. The Solutions dryers feature the same double-wall construction as Anatol’s gas dryers, re-enforced with high-efficiency thermal insulation to improve air circulation. Solutions Series electric dryers offer programmable temperature controls with automatic cool-down. Solutions electric dryers are available in seven configurations, with four basic models, from 24” belts with 4’ of heat up to 60” belts with 10’ of heat.


Model # Belt Width Oven Length Standard Infeed
Outfeed Length
Overall Length Air Circulation Electrical Requirements Exhaust Duct Size
SED-2404A-5800 24"
(61cm)
4'
(122cm)
5’
(152cm)
9'
(274cm)
Yes 1 Ph, 208-230 V, 5.85 kW, 29A, 50/60Hz
3 Ph, 208-230 V, 5.85 kW, 17A 50/60 Hz
4"
(10cm)
SED-2404S-7800 24"
(61cm)
4'
(122cm)
5’
(152cm)
9'
(274cm)
Yes 1 Ph, 208-230 V, 7.8 kW, 39A, 50/60Hz
3 Ph, 208-230 V, 7.8 kW, 23A 50/60 Hz
4"
(10cm)
SED-3606A-13000 36"
(91cm)
6'
(183cm)
5’
(152cm)
11'
(335cm)
Yes 1 Ph, 208-230 V, 13 kW, 63A, 50/60 Hz
3 Ph, 208-230 V, 13 kW, 36A 50/60 Hz
4"
(10cm)
SED-3606A-15600 36"
(91cm)
6'
(183cm)
5’
(152cm)
11'
(335cm)
Yes 3 Ph, 208-230 V, 15.6 kW, 43A 50/60 Hz 4"
(10cm)
SED-3610A-23400 36"
(97cm)
9'5"
(287cm)
10'
(152cm)
19'5"
(594cm)
Yes 3 Ph, 208-230 V, 23.4 kW, 66A 50/60 Hz 4"
(10cm)
SED-4810A 48"
(122cm)
9'5"
(287cm)
10'
(152cm)
19'5"
(594cm)
Yes 3 Ph, 208-230 V, 26 kW, 73A 50/60 Hz 6"
(15cm)
SED-6010A 60"
(152cm)
9'5"
(287cm)
10'
(152cm)
19'5"
(594cm)
Yes 3 Ph, 208-230 V, 31.2 kW, 88A 50/60 Hz 6"
(15cm)
Photos

Control Panel

  • Digital control panel
  • Solid-state variable belt speed control, set in ft/min or meters/min
  • Programmable temperature controller (accuracy: +/- 1º)
  • Automatic controlled start up and cool down mode
  • Reversible belt direction

Belt

  • Adjustable infeed/outfeed openings
  • Teflon-coated fiberglass belt
  • Heavy-duty conveyor rollers

Heating Elements

  • 12-48 ceramic heating elements
  • Adjustable heat panels (raise or lower)

Construction

  • Industrial grade AC motor
  • Double wall insulation with galvanized interior
  • Heavy-duty multi-section construction
  • Air-cooled control cabinet
  • Stainless steel slide out filters (larger models only)
    • Infeed/outfeed exhaust hoods
    • Increase control of air circulation.
    • Custom infeed/outfeed extensions
    • Allow you to run a press on each side of the infeed belt.
    • Outfeed cooling fan
    • Cools garments more quickly and ensures ink is cured before it’s removed from the belt.
    • Single phase
    • Accommodates facilities with single phase power requirements.
      • Solutions 24” belt width/4’ heat
      • Solutions 36” belt width/6’ heat
      • Solutions 48” belt width/10’ heat
      • Solutions 60” belt width/10’ heat
      • Custom configurations available upon request
  • Equipment Certification

    European Committee for Standardization® (CE) and Underwriters Laboratories® (UL) compliant: built to specifications established by both CE and UL
