Horno de secado Solutions

Horno de banda eléctrico es Eficiente y Accesible.

Disponible en cuatro modelos básicos en configuraciones de: 24″ ancho de banda/4′ tunel de calor – 60″ ancho de banda/10′ tunel de calor.

Cotizar aquí

Descripción

Cuando el gas no es una opción, los hornos eléctricos de banda Anatol es la solución perfecta. Los hornos de la series Solutions son ideales para los serigrafístas de camisetas y textil que buscan una unidad de curación eficiente y accesible. Cuentan con más paneles de calefacción de cerámica que los secadores similares guarda incluso el calor en toda la cámara. Los hornos Solutions cuentan con la misma construcción de doble pared que los secadores de gas Anatol, reforzados con aislamiento térmico de alta eficiencia para mejorar la circulación del aire. Los hornos eléctricos Serie Solutions ofrecen controles de temperatura programables con enfriamiento automático. Los hornos eléctricos Solution están disponibles en siete configuraciones, con cuatro modelos básicos, desde bandas de 24″ ancho de banda con 4′ tunel de calor hasta 60″ ancho de banda con 10′ tunel de calor.

Características estándar

Panel de Control
  • Panel de control digital
  • Control de velocidad variable de la banda de estado sólido
  • ajustado en pies/min o metros/minuto
  • Regulador de temperatura programable (precisión: +/- 1º)
  • Modo automático de arranque y enfriamiento controlado
  • Dirección reversible de la banda
Elementos de Calentamiento
  • 12-48 Elementos calefactores cerámicos
  • Paneles térmicos ajustables (subir o bajar)
Construcción
  • Motor de AC de grado industrial
  • Aislamiento de pared doble con interior galvanizado
  • Construcción alta resistencia de todas sus secciones
  • Gabinete de control refrigerado por aire
  • Filtros internos removibles de acero inoxidable (sólo modelos más grandes)
Banda
  • Orificios de entrada / salida ajustables
  • Banda de fibra de vidrio recubierta de teflón
  • Rodillon transportador de Banda para servicio pesado

Solutions Specifications



Model #Belt WidthHeat
Chamber
with
Smoke Hood
Overall
Length
Smoke
Hood
Length
 Standard
Infeed/Outfeed
Length
WattageCeramic
Elements
Electrical Requirements
SED200320’’
50cm
3’0’’
91.5 cm
7’0’’
213.5 cm
2’0″/2’0″
61cm/61cm
390061PH 208-230V, 50/60 Hz,3,6 kW,17A
3PH 208-230V, 50/60 Hz,3,6 kW,10A
SED240424’’
61cm
4’0’’
125 cm
9’0’’
275 cm
0’10’’
25 cm
2’6″/2’6″
75cm/75cm
585091PH 208-230V, 50/60 Hz,5,85 kW,29A
3PH 208-230V, 50/60 Hz,5,85 kW,17A
SED240424’’
61cm
4’0’’
125 cm
9’0’’
275 cm
0’10’’
25 cm
2’6″/2’6″
75cm/75cm
7800121PH 208-230V, 50/60 Hz,7,8 kW,38A
3PH 208-230V, 50/60 Hz,7,8 kW,22A
SED240624’’
61cm
6’0’’
185 cm
11’0’’
335 cm
0’10’’
25 cm
2’6″/2’6″
75cm/75cm
11700181PH 208-230V, 50/60 Hz,11,7 kW,56A
3PH 208-230V, 50/60 Hz,11,7 kW,33A
SED360636’’
92cm
6’0’’
185 cm
11’0’’
335 cm
0’10’’
25 cm
2’6″/2’6″
75cm/75cm
15600241PH 208-230V, 50/60 Hz,15,6 kW,75A
3PH 208-230V, 50/60 Hz,15,6 kW,44A
SED361036’’
92cm
9’5’’
287 cm
19’5’’
591 cm
5’0″/5’0″
150cm/150cm
23400363PH 208-230V, 50/60 Hz,23,4 kW,65A
SED480648’’
122cm
6’0’’
185 cm
11’0’’
335 cm
0’10’’
25 cm
2’6″/2’6″
75cm/75cm
17550271PH 208-230V, 50/60 Hz,17,5 kW,85A
3PH 208-230V, 50/60 Hz,17,5 kW,49A
SED481048’’
122cm
9’5’’
287 cm
19’5’’
591 cm
0’10’’
25 cm
5’0″/5’0″
150cm/150cm
27300423PH 208-230V, 50/60 Hz, 27,3 kW,78A
SED601060’’
152cm
9’5’’
287 cm
19’5’’
591 cm
0’10’’
25 cm
5’0″/5’0″
150cm/150cm
31200483PH 208-230V, 50/60 Hz, 31,2 kW,87A

Descargue el folleto

Descargue el folleto

Cerfificación y garantía

Cerfificación y garantía

Two-Year Limited Warranty

Every effort has been made to ensure the accuracy of the promotional information included in this brochure. Specifications are subject to change. Anatol Equipment Manufacturing Co. and its subsidiaries, if any, expressly disclaim any liability for damages, consequential or incidental, resulting from the purchase, transportation, installation, or use of any products based upon information contained within this brochure. Any rights or remedies are limited solely to those provided in writing by Anatol Equipment Manufacturing Co. at the time of sale.
