Unidad de revelado UV LED

Unidad de exposición Aurora UV LED

Reduzca el Tiempo de Instalación y Disminuya Los Costos de Energía.

Disponible en cuatro modelos, con un tamaño de Area de: 23″ x 33″ ó 26″ x 36″ (para pantallas individuales) o 26″ x 43″ ó 52″ x 36″ (expone dos marcos al mismo tiempo).

Cotizar aquí

Descripción

La unidad de exposición Aurora UV cura las pantallas de forma rápida, uniforme y eficiente. Expone pantallas en segundos, mientras que le da detalles nítidos y medios tonos de alta resolución, con una exposición uniforme en toda la pantalla. Con una larga duración LED diseñado para durar 50.000 horas, la unidad de exposición Aurora UV LED no requiere ningún tiempo de arranque o enfriamiento, mantiene las temperaturas bajas y es menos costoso de mantener que las unidades de haluro metálico. Deje que la Aurora acorte sus tiempos de instalación y reduzcan sus costos de energía hoy. Esta unidad de exposición está diseñada para una operación de un toque, desde el control de la pantalla táctil de 7,5 pulgadas hasta las cerradura giratoria. Esta unidad de exposición está disponible con un tamaño de pantalla máximo de 26″ x 36″ (para marcos individuales), o 26″x43″ ó 52″x36″ (expone dos marcos al mismo tiempo).

Características estándar

Controles de pantalla táctil
  • Pantalla táctil de 7.5″ con sistema operativo Aries
  • Controles sencillos de un solo toque
  • Expone pantallas en modo automático o modo manual
  • Ajustes para los tiempos de vacio y de exposición
  • Programe y guarde hasta 8 configuraciones
Fuente de luz
  • Larga vida útil de los LEDs: 50.000 horas
  • Amplio espectro de luz (390-405)
  • Luces de seguridad para facilitar la alineación adecuada de los positivos
Area de Exposición
  • Tres opciones de tamaño máximo de pantalla:
  • 23″ x 33″
  • 26″ x 36″
  • 26″ x 43″ (para dos pantallas)
  • 52″ x 36″ (para dos pantallas)
Cubierta y Vacío
  • El caucho de neopreno crea un sello apretado a la cubierta-a-pantalla para el mejor contacto emulsión-película-vidrio
  • Cerrojo giratorio en el marco permite una sola mano de operación de apertura y cierre de la cubierta de vacío
Construcción
  • Vidrio templado opticamente transparente de 1/4″
  • Sistema de filtración de aire en gabinete de luz para mantener el vidrio y las luces limpias
  • Gabinete de acero de alta resistencia
  • Fundas extraíbles para un fácil acceso al interior para la limpieza
  • Enviados completamente montados y listos para la producción
  • Incluye Bomba de Vacío (140 L/min)
  • Soporte incluido

Especificaciones de Aurora Unidad de revelado UV LED



Modelo #Bomba de VacíoTamaño Máximo del MarcoExposure Unit o.d.
(l.w.h.)*
Requerimientos Eléctricos
AURORALEDEXP-23X33140 L/min23” x 33”
(58cm x 84cm)
42.5” x 38.6” x 10.2”
(108cm x 98cm x 26cm)
1 Phase, 110V, 6A
1 Phase, 208V/230V, 3A
AURORALEDEXP-26X36140 L/min26” x 36”
(66cm x 91cm)
47.2” x 41.3” x 37.4”
(120cm x 105cm x 95cm)
1 Phase, 110V, 9A
1 Phase, 208V/230V, 5A
AURORALEDEXP-26X43140 L/min x226” x 43”
(66cm x 109cm)
57.1” x 47.2” x 39.4”
(145cm x 120cm x 100cm)
1 Phase, 110V, 15A
1 Phase, 208V/230V, 8A
AURORALEDEXP-52X36140 L/min x252” x 36”
(132cm x 91cm)
66.9″ x 52″ x 39.4″
(170cm x 132cm x 100cm)
1 Phase, 208V/230V, 10A
AURORALEDEXP-50X60140 L/min x250” x 60”
(127cm x 153cm)
80″ x 71,3″ x 39.4″
(203cm x 181cm x 100cm)
3 Phase, 208V, 6.67A
1 Phase, 208V/230V, 11A
