Presecador Comet Light

La velocidad y eficiencia del curado instantáneo con cuarzo en nuestro paquete más asequible.

Modelos disponibles con áreas de curado de 16 “x 18”, 20 “x 24” o 20 “x 28”.

Cotizar aquí

Descripción

La velocidad y la eficiencia del curado instantáneo de cuarzo en nuestro paquete más asequible.

La unidad de curado por flash Comet Light de Anatol fue diseñada para aumentar la eficiencia de su tienda en comparación con los flashes infrarrojos, al mismo tiempo que es accesible para tiendas con un presupuesto limitado. Simplemente configure su tiempo de curado y el sensor óptico en la unidad de flash detectará automáticamente cuando hay una camisa debajo, activando y desactivando las lámparas en consecuencia. Comet Light está disponible en tres áreas de curado diferentes: 16″ x 18″, 20″ x 24″ y 20″ x 28″, y es compatible con las prensas automáticas y manuales Anatol (tenga en cuenta que el flash se controla de forma independiente. Los flashes Comet Light no se pueden controlar directamente desde la pantalla táctil principal de la prensa automática).

Características estándar

Una alternativa inteligente a las unidades de curado por flash infrarrojo a un precio accesible.
  • Establezca el tiempo de flash deseado con el controlador digital fácil de usar.
  • El sensor de paletas detecta cuando una camisa está debajo del flash para activación/desactivación automática, por lo que las lámparas solo están “encendidas” cuando es necesario; reduciendo la energía en comparación con los flashes infrarrojos que siempre están encendidos.
  • Las lámparas de cuarzo se calientan y se enfrían rápidamente.
  • Múltiples zonas de curado: dos o tres zonas dependiendo del tamaño del flash (ver Especificaciones).
  • Disponible en un soporte de suelo de altura ajustable para su uso con prensas de serigrafía tanto automáticas como manuales de Anatol.

Comet Light Specifications



SIZENumber of Curing ZonesNumber of LampsElectrical Requirements*
16” x 18”
(40.6cm x 45.7cm)
291 Ph, 208-240V, 50/60 Hz, 9kW, 43A
3 phase 208V 25 A
20” x 24”
(50.8cm x 61cm)
2101 Ph, 208-240V, 50/60 Hz, 12,5kW, 60A
3 phase 208V 35 A
20” x 28”
(50.8cm x 71.1cm)
3151 Ph, 208-240V, 50/60 Hz, 18,75kW, 90A
3 phase 208V 52 A

Descargue el folleto

Descargue el folleto

Cerfificación y garantía

Cerfificación y garantía

Two-Year Limited Warranty

Every effort has been made to ensure the accuracy of the promotional information included in this brochure. Specifications are subject to change. Anatol Equipment Manufacturing Co. and its subsidiaries, if any, expressly disclaim any liability for damages, consequential or incidental, resulting from the purchase, transportation, installation, or use of any products based upon information contained within this brochure. Any rights or remedies are limited solely to those provided in writing by Anatol Equipment Manufacturing Co. at the time of sale.

Equipment Certification

European Committee for Standardization® (CE) and Underwriters Laboratories® (UL) compliant: built to specifications established by both CE and UL

All equipment shipped to Canada is Approved under the Special Inspection Program per SPE-1000
