Timer MaxWell PTF100

Name: Timer MaxWell PTF100
Brand: Anatol
SKU: 6000151
Price: 93.49 USD
Availability: InStock

$93.49

Part Number: 6000151

Categories: Electrical parts

Used For: Comet Pro Flash Cure Unit, Quick Light, Timer Box

The Timer MaxWell PTF100 is a 240V programmable timer designed for precise control in Comet Light Pro, Quick Light, and Timer Box systems. Featuring multiple timer modes, relay output, and an easy-to-use interface, it’s ideal for industrial automation, HVAC, irrigation, and security systems. Compact yet powerful, it supports a timing range from 0.1 seconds to 18 hours for flexible operation.

SPECIFICATIONS
● Digital programmable timer
● 48mm*48mm, LCD display,6 digits
● Display format,00.00.00, seconds,minutes,hours
● Panel mount type
● Dry contact, NPN input
● Maximum 4 outputs(Relay or SSR Drive)
● 85~265Vac or 24VDC source
● Reset and cycle function
● Works with all kinds of switch
● Memory retention function
● Relay on delay or off delay configurable
● CE comply
● Used for: Comet Light Pro, Quick Light, Timer Box
