Description
An ink mixer is a vital piece of equipment in a professional screen printing shop. The Anatol Formulator Double Screen Printing Ink Mixer is ideal for mixing plastisol or water-based inks, for adding pigments such as glitters and fluorescents to bases, and for ensuring thorough blending of reducers and other modifiers. The self-centering feature automatically adjusts the Formulator to hold a wide variety of ink containers , from 1 quart up to 6 gallons, two containers at a time! The mixer’s special blade configuration with «lift and roll» movement provides gentle, thorough mixing without splash-up or air bubbles, and prevents ink from settling in the sides or bottom of the container. The Formulator offers fixed and variable speed options, and can rotate either clockwise or clockwise.
Standard Features
Construction
- Variable speed AC electric motor
- Heavy-duty steel construction
- Self-centering clamp
- Easily-adjustable touchscreen angle for convenient access
Operation
- Easy-to-use touchscreen control panel
- Change mixing direction (clockwise, counterclockwise)
- Quick and easy changeover for different blade sizes
- Set mixing speed, time and direction and quickly save and recall up to 6 different programs
Ink Mixer Double Specifications
| MODEL | WEIGHT | INK VOLUME | OUTER DIMENSIONS WXDXH | ELECTRICAL REQUIREMENTS |
|---|---|---|---|---|
| DOUBLE MIXER | 207lbs (94 kg) |
up 1/4G (0.95L) x2 to 6G (22.7L) x2 |
38.2” x 26.1” x 33.4” 970mm x 663mm x 847.5 mm |
1 Phase, 110V, 15A 1 Phase 208-240V, 13A |
